Prima Mu Microscope

MULTI-DISCIPLINARYPRIMA MUMICROSCOPE

The Prima Mu is intended for routine inspection and in screening clinical environments. A well-designed apochromatic optical system with a high output LED built directly into the microscope housing provides users with a compact solution. The arm system has been carefully designed to mitigate vibration and lower the system's center of gravity to provide a more stable, lighter weight solution.

• Binocular Tube

  45° inclined (standard), 0-210° inclinable, straight head (optional)

• Eyepiece

  WF 10X/18mm with retractable eye guards, diopter adjustment ±5mm with diopter lock; optional: WF 12.5X/18mm

• Apochromatic Magnichanger

  0.6X, 1.0X, 1.6X

• Objective

  f-250 mm with fine focus (standard); Options: NuVar with focal length adjustment f-300-400 mm, f-200-400 mm; f-300 mm or f-400 mm with fine focus; f-200 mm fixed objective; objective lens protector.

• Light Source

  27W LED / 75K lux

• Built-in-Filters

  Green & Yellow

• Vertical Movement of arm

  ± 250 mm, power saving feature with light cut-off in park position

• Mounting Options

  Floor stand, wall mount and ceiling mount

• Microscope carriers

  120° carrier

• Stand

  H-base on 4 locking castor wheels

• Package Contents
  • Tools for Securing Base and Pillar
  • Sterilizable Knob Covers
  • Nylon Dust Cover
• Accessories (Optional)
Accessories (Optional)
• Assistant viewer bridge
• Beam splitters (straight/inclined)
• Ergonomic viewing tube, tilting 0 - 210 ̊
• ProLine accessories and camera adapters
• T-handle kit (dual front handle is optional)
• Dual handle
•
